EJOT® Concrete screw JC2-IT 6

Produktbild1
Produktbild2

Specification

  • Applications

    • Pipe brackets
    • Profile rails

  • Properties

    • Galvanized zinc-plated steel
    • Hexagon head with internal thread M8/M10
    • ETA-approved concrete screw for cracked and non-cracked concrete
    • Self-tapping approved screw anchor for push-through installation
    • No expansion forces, hence small edgee and centre distances possible
    • Completely removable
    • For dry indoor areas

  • Embedment substrates

    • Approved for cracked concrete and non-cracked concrete
    • Also suitable for pre-stressed hollow core slab, bricks and solid brick sandstone

Filter

Selected filters

    Orderidentifier Article Number Embedment depth hef≥ mm Length mm Drill hole depth mm Pilot Hole Ø mm Unit
    JC2-IT 6x45 M8/M10 9650071504 40.0 45.0 65.0 6.0 50

    Specifications

    Embedment depth hef≥
    40.0
    Length
    45.0
    Drill hole depth
    65.0
    Pilot Hole Ø
    6.0
    Orderidentifier
    JC2-IT 6x45 M8/M10
    Unit
    50
    JC2-IT 6x60 M8/M10 9650071509 40.0 60.0 65.0 6.0 50

    Specifications

    Embedment depth hef≥
    40.0
    Length
    60.0
    Drill hole depth
    65.0
    Pilot Hole Ø
    6.0
    Orderidentifier
    JC2-IT 6x60 M8/M10
    Unit
    50
