Mesh sleeve USF

Siebhuelse_Pos2
Produktbild2

Specification

  • Applications

    • For embedment in perforated brick

  • Properties

    • Guarantees exact calibration of threaded rod

  • Note

    For planning and processing, please observe ETA-16/0089

Filter

Selected filters

    Orderidentifier Article Number Length mm Thread diameter mm Hole depth

    h1 ≥ mm

    		suitable for thread Unit
    M8 10 Mesh sleeve USF 12x80 9571012080 80.0 12.0 85.0 M8 10

    Specifications

    Length
    80.0
    Thread diameter
    12.0
    Hole depth

    h1 ≥

    85.0
    suitable for thread
    M8
    Orderidentifier
    M8 10 Mesh sleeve USF 12x80
    Unit
    10
    M8 / M10 10 Mesh sleeve USF 16x85 9571016085 85.0 16.0 90.0 M8, M10 10

    Specifications

    Length
    85.0
    Thread diameter
    16.0
    Hole depth

    h1 ≥

    90.0
    suitable for thread
    M8, M10
    Orderidentifier
    M8 / M10 10 Mesh sleeve USF 16x85
    Unit
    10
    M8 / M10 10 Mesh sleeve USF 16x130 9571016130 130.0 16.0 135.0 M8, M10 10

    Specifications

    Length
    130.0
    Thread diameter
    16.0
    Hole depth

    h1 ≥

    135.0
    suitable for thread
    M8, M10
    Orderidentifier
    M8 / M10 10 Mesh sleeve USF 16x130
    Unit
    10
    M12 / M16 10 Mesh sleeve USF 20x85 9571020085 85.0 20.0 90.0 M12-M16 10

    Specifications

    Length
    85.0
    Thread diameter
    20.0
    Hole depth

    h1 ≥

    90.0
    suitable for thread
    M12-M16
    Orderidentifier
    M12 / M16 10 Mesh sleeve USF 20x85
    Unit
    10
    M12 / M16 10 Mesh sleeve USF 20x130 9571020130 130.0 20.0 135.0 M12-M16 10

    Specifications

    Length
    130.0
    Thread diameter
    20.0
    Hole depth

    h1 ≥

    135.0
    suitable for thread
    M12-M16
    Orderidentifier
    M12 / M16 10 Mesh sleeve USF 20x130
    Unit
    10

    Multifix Calculator

    Calculate the mortar cartridges required for your project with this calculation tool. It will help you to reduce waste and make your installation more cost-effective.

    • Select thread diameter from the list on the far left.
    • Select the number of holes to fill by entering them in the text box above the illustration or alternatively use the plus and minus buttons.
    • Select the drilling depth using the plus and minus buttons in the illustration.
    • Done! The number of mortar cartridges required is now displayed.
